KLE-137 series require an arm separately for installation. (Adaptable arm diameter: φ34.0, φ48.6 or φ60.5mm)
Optical Versatility (※KLE-137-52L only)
Light distribution patterns are variable.
KLE-137-52L provides two different light distribution patterns, allowing the choice between wide and area type in accordance with installing sites.
Arm Mounting Hole
Adjustable for three different size of mounting arms, φ34.0, φ48.6 or φ60.5mm.
Having structure to maintain the center of line of mounting arm, the outer appearance is enhanced when the luminaire is installed.
| Model Name |
Lamp | Housing | Cover | Standard Color |
Weight （kg） |
Voltage （V） |
Input Current （A） |
|---|---|---|---|---|---|---|---|
| KLE-137-52L | LED 2W type X24 |
ADC | Acrylic Resin |
Metallic Silver |
5.8 | 220 AC 240AC |
0.243 0.235 |
| KLE-137-75 | LED 2W type X32 |
6.0 | 0.355 0.326 |
||||
| KLE-137-81 | LED 2W type X38 |
0.378 0.350 |
|||||
| KLE-137-92 | LED 2W type X42 |
6.1 | 0.430 0.392 |
| Model Name |
Power Consumption （W） |
Luminous Flux （lm） |
Luminous Efficiency （lm/W） |
Lamp Life （hr）※1 |
Color Temperature （K） |
|---|---|---|---|---|---|
| KLE-137-52L | 52 | 5,720 | 110 | 60,000 | 5,000 |
| KLE-137-75 | 75 | 8,300 | 110.6 | ||
| KLE-137-81 | 81 | 9,100 | 112.3 | 50,000 | |
| KLE-137-92 | 92 | 9,800 | 106.5 |
★Light control is not equipped.
※1：Lumen maintenance factor 70％
KLE-137 series are manufactured in Japan.
