Model Name |
Lamp | Housing | Cover | Standard Color |
Weight (kg) |
Voltage (VAC) |
Input Current (A) |
---|---|---|---|---|---|---|---|
KLS-712-7M | LED x 108 | ADC | Tempered glass |
Gray | 4.8 | 100 - 240 | 0.35 |
KLS-712-12M | LED x 192 | 6.5 | 0.55 |
Model Name |
Power Consumption (W) |
Lumen Output (lm) |
Luminous Efficiency (lm/W) |
Lamp Life (hr)※1 |
Color Temperature (K) |
Ingress Protection |
Mechanical Impact Protecion |
Withstand Voltage Surge (kV) |
---|---|---|---|---|---|---|---|---|
KLS-712-7M | 75 | 9,000 | 120 | 60,000 | 5,000 | IP66 | IK09 | 20 |
KLS-712-12M | 120 | 14,400 |
NEMA socket for 7 terminals and dimmable feature. Dimmable power supply (0 -10 V DC/PWM)
※1:Lumen maintenance factor 70%
